Plot Method for fash Objects

Generates a plot for a fash object, providing either a heatmap of posterior weights or a structure plot summarizing component contributions across datasets.

# S3 method for class 'fash'
plot(
  x,
  plot_type = c("heatmap", "structure", "function"),
  ordering = NULL,
  discrete = FALSE,
  selected_unit = NULL,
  ...
)

Arguments

x

A fash object containing the results of the FASH pipeline.

plot_type

A character string specifying the type of plot to generate. One of: - "heatmap": Bubble/heatmap plot of posterior weights (default). - "structure": Structure plot of mixture components. - "function": Plot fitted effect function for a selected unit.

ordering

A character string specifying the method for reordering datasets in the structure plot. Only used if plot_type = "structure".

- "mean": Reorder by the mean of the posterior PSD. - "lfdr": Reorder by the local false discovery rate. - NULL: No reordering (default).

discrete

A logical value. If TRUE, treats PSD values as discrete categories with distinct colors in the structure plot. Ignored if plot_type = "heatmap" or "function".

...

Additional arguments passed to plot_heatmap, fash_structure_plot or plot_function,

Value

A plot object (typically a ggplot).

Examples

set.seed(1)
data_list <- list(
  data.frame(y = rpois(5, lambda = 5), x = 1:5, offset = 0),
  data.frame(y = rpois(5, lambda = 5), x = 1:5, offset = 0)
)
grid <- seq(0, 2, length.out = 10)
fash_obj <- fash(data_list = data_list, Y = "y", smooth_var = "x", offset = "offset", grid = grid, likelihood = "poisson", verbose = TRUE)
#> Starting data setup...
#> Completed data setup in 0.00 seconds.
#> Starting likelihood computation...
#>
  |
  |                                                                      |   0%
  |
  |===================================                                   |  50%
  |
  |======================================================================| 100%
#> Completed likelihood computation in 0.08 seconds.
#> Starting empirical Bayes estimation...
#> Completed empirical Bayes estimation in 0.00 seconds.
#> fash object created successfully.

# Heatmap plot
plot(fash_obj)


# Structure plot
plot(fash_obj, plot_type = "structure", ordering = "mean", discrete = TRUE)
